- Tri-Sensor Core
- 2K High-Definition Video
- Three-Axis Stabilized Gimbal
- Precision Operation
- Quick-Release Design
- Water Resistance Rating
| Input Voltage | 12 - 50V |
|---|---|
| Power | <10W |
| Weight | 482.9g |
| Dimension | 126 * 97 *134 mm |
| Operating Temp. | -10°C ~ 65°C |
| Storage Temp. | -20°C ~ 70°C |
| Memory Card | Micro SD Card |
| Interface | RJ45 Ethernet (IP) |
| Angle Vibration | ±0.008° |
|---|---|
| Control Range | Pitch: +45° to -90°, Yaw: 360° |
| Structure Range | Pitch: -132.5° to 73°, Roll: ±60°, Yaw: ±360° |
| Control Speed | Pitch: 120°/s, Yaw: 180°/s |
| CMOS | 1/2.8" Sony Starvis CMOS Sensor |
|---|---|
| Pixel | 5.14M pixels |
| Optical Zoom | 10x" (for magnification or zoom) F=5mm ~ 50 mm |
| F-number | F1.4 ~ F2.5 |
| FOV | 6°~46° (Horizontal) ; 3°~24° (Vertical) |
| Sensitivity | 0.008 lux (color) , 0.003 lux (black & white) |
| Resolution | 2592x1944 @ 30fps, 2592x1520 @ 30fps, 1920x1080 @ 30fps, 1280x720 @ 30fps, 640x480 @ 30fps |
| DRI（M）(1.8m*0.5m) | D:5910 R:1470 I:740 |
| Vid | H.264+ / H.264 / M-JPEG |
| Sensor | non-cooler LWIR |
|---|---|
| Resoultion | 640*480 @ 30fps |
| Lens | 18mm Fixed-fouse lens |
| Sensitivity | <50mk |
| DRI（M）(1.8m*0.5m) | D : 560 R : 140 I : 70 |
| Laser Wavelength | 905 ± 20nm |
|---|---|
| Measure Range | 5 meters ~ 3,600 meters |
| Laser Power | Class 2, <1mW |
| Accuracy | ±0.4% x Distance |
